| Pneumatic Controls |  |
| Control # | Air Terminal Type | Sequence | Heating Coils | T'Stat (DA/RA) | Cold Damper (NO/NC) | Hot Damper (NO/NC) | Airflow Sensor |
|---|---|---|---|---|---|---|---|
| SD-P-3100 | Single Duct | VAV Cooling | H.W. (Optional) | Direct Acting | Normally Open | ||
| SD-P-3200 | Single Duct | VAV Cooling | H.W. (Optional) | Direct Acting | Normally Closed | ||
| SD-P-3300 | Single Duct | VAV Cooling | H.W. (Optional) | Reverse Acting | Normally Open | ||
| SD-P-3400 | Single Duct | VAV Cooling | H.W. (Optional) | Reverse Acting | Normally Closed | ||
| SD-P-3120 | Single Duct | Morning Warm-Up | H.W. (Optional) | Direct Acting | Normally Open | ||
| SD-P-3220 | Single Duct | Morning Warm-Up | H.W. (Optional) | Direct Acting | Normally Closed | ||
| SD-P-3320 | Single Duct | Morning Warm-Up | H.W. (Optional) | Reverse Acting | Normally Open | ||
| SD-P-3420 | Single Duct | Morning Warm-Up | H.W. (Optional) | Reverse Acting | Normally Closed | ||
| SD-P-3140 | Single Duct | VAV Htg & Clg (Auto Changeover) | H.W. (Optional) | Direct Acting | Normally Open | ||
| SD-P-3240 | Single Duct | VAV Htg & Clg (Auto Changeover) | H.W. (Optional) | Direct Acting | Normally Closed | ||
| SD-P-3340 | Single Duct | VAV Htg & Clg (Auto Changeover) | H.W. (Optional) | Reverse Acting | Normally Open | ||
| SD-P-3440 | Single Duct | VAV Htg & Clg (Auto Changeover) | H.W. (Optional) | Reverse Acting | Normally Closed | ||
| SD-P-3160 | Single Duct | VAV Cooling & VAV Heating | H.W. (Optional) | Direct Acting | Normally Open | ||
| SD-P-3260 | Single Duct | VAV Cooling & VAV Heating | H.W. (Optional) | Direct Acting | Normally Closed | ||
| SD-P-3360 | Single Duct | VAV Cooling & VAV Heating | H.W. (Optional) | Reverse Acting | Normally Open | ||
| SD-P-3460 | Single Duct | VAV Cooling & VAV Heating | H.W. (Optional) | Reverse Acting | Normally Closed | ||
| SD-P-3175 | Single Duct | Dual Minimum (Reheat) | H.W. (Optional) | Direct Acting | Normally Open | ||
| SD-P-3275 | Single Duct | Dual Minimum (Reheat) | H.W. (Optional) | Direct Acting | Normally Closed | ||
| SD-P-3375 | Single Duct | Dual Minimum (Reheat | H.W. (Optional) | Reverse Acting | Normally Open | ||
| SD-P-3475 | Single Duct | Dual Minimum (Reheat | H.W. (Optional) | Reverse Acting | Normally Closed | ||
| SD-P-3180 | Single Duct | Constant Volume | H.W. (Optional) | Direct Acting | Normally Open | ||
| SD-P-3280 | Single Duct | Constant Volume | H.W. (Optional) | Reverse Acting | Normally Closed | ||
| SD-P-3181 | Single Duct | 2 Level Constant Volume | H.W. (Optional) | Normally Open | |||
| SD-P-3281 | Single Duct | 2 Level Constant Volume | H.W. (Optional) | Normally Closed | |||
| SD-P-0001 | Single Duct | H.W. (Optional) | Direct Acting | Normally Closed | |||
| SD-P-0002 | Single Duct | H.W. (Optional) | Reverse Acting | Normally Open | |||
| SD-P-0003 | Single Duct | Static Pressure Control | Normally Open | ||||
| SD-P-0004 | Single Duct | Static Pressure Control | Normally Closed | ||||
| DD-P-3000 | Dual Duct | Dual Maximum | Direct Acting | Normally Open | Normally Closed | Hot, Total | |
| DD-P-3004 | Dual Duct | C.V. Mixing | Reverse Acting | Normally Closed | Normally Open | Cold, Total | |
