Standard Features
- RRPL-P19 (Approved by NY State Office Of Mental Health): 12 GA C.R.S. perforated face with 1/8" diameter holes on 3/16" staggered centers (Pattern P19)
- RRPL Face Plate: Other face hole patterns available
- Sleeve: 12 GA steel sleeve with continuous welds to face plate (specify sleeve length D)
Finish
- Standard: White Powder Coat Finish
- Optional: Rust Inhibiting Prime Coat. Consult factory for other finishes
Optional Features
- Material Gauges: 3/16", 10 GA
locking angle/frame - 1/8", 1/4"
- Material: Stainless Steel, Aluminum, or Galvanized (consult factory for availability)
- Opposed Blade Damper: rear operated
- Anchoring Studs: Nelson-Type for poured concrete/brick wall applications
- Locking Angles: Two pieces 1" x 1" x 3/16" (Long sides & shipped loose for field installation)
- Locking Angle Frame: 1" x 1" x 3/16" welded one piece steel angle (shipped loose for field installation). Other sizes available - consult factory.
- Face Screw Holes & Screws: #10 x 1-1/2" Tamper-Proof flat head pin-torx
- Rear Auxiliary Mounting Frame: face screw holes & Tamper-Proof flat head pin-torx screws attach to rear frame
Construction
The steel face plate is continuously welded to the sleeve. Optional locking angles / locking frame / face screw holes-screws / rear auxiliary frame shipped loose for field installation. The optional damper is welded inside the sleeve and operated from the rear of the unit.
Installation
The RRPL security diffusers are installed in risk resistant ceiling applications by one of the methods described above. |
|
|
 |
|
